3 Cell 3 Inch 3x7W 5CCT Tunable Square Gimbal Downlights

3 Cell 3” Gimbal Downlights3 Cell 3” Gimbal Downlights3 Cell 3” Gimbal Downlights3 Cell 3” Gimbal Downlights3 Cell 3” Gimbal Downlights3 Cell 3” Gimbal Downlights
Product Features:
  • New style 3 cell 3 inch 3x7w square gimbal downlights.
  • 5CCT selectable in one fixture.
  • Fast & Easy Installation: Save labor cost.
  • Junction Box Included: No additional hardware required.
  • Gimbal Design: 360 horizontal rotation and 90°tilt.
  • Suit for damp locations.

3 Cell 3 Inch 3x7W 5CCT Tunable Square Gimbal Downlights

Floating gimbal downlight

features of gimbale downlight

5 color temperature in one fixture and tunable

Lighting effect

product details of gimbal downlight

Neasy to install

input voltage AC 120v

more color for choice

more size for choice

3 inch floating gimbal downlight

applications of 3 inch floating gimbal downlight

3 Cell 3 Inch 3x7W 5CCT Tunable Square Gimbal Downlights

Adjustable: The 3 inch gimbal cob downlight supports 360° horizontal rotaion, you can switch lighting angles at will. It is Ideal for higher ceilings or for focused area illumination. The CRI90+ highlights all your decorations with vivid and natural lighting.

5CCT: 2700K 3000K 3500K 4000K 5000K in one fixture, you can freely change the light color at will.

Great Durability: The light fixture and j-box are both IC rated, letting it be able to be in contact with combustible materials. The airtight structure effectively prevents heated airflow diffusion. The metal light body makes it durable and able to be used in damp locations.

Energy Efficiency: With the same brightness as a 80W incandescent lamp, this 9W LED downlight reduces your energy usage and electricity bills while still being suitable with AC120V input voltage.

Smooth Dimming: This light is compatible with the majority of LED dimmers on the market and can smoothly dim from 10% to 100%, allowing it to fit a wide range of lighting applications such as in kitchens, living rooms, bedrooms and bathrooms.

Model JXL-COB03-S21W-5CCT
Style 3 Cell Inch 5CCT Gimbal Downlight
Wattage 3x7W
Input Voltage 120V AC, 50/60HZ
Luminous Flux 2000LM
Efficiency 80LM/W
CRI >90Ra
Color Temp 2700K/3000K/3500K/4000K/5000K Selectable
Dimming Triac dimming 10-100%
Material ‎Aluminum
Shape Square
Dimensions L240*W90*H29.5mm
Cut Out Size L220*W80mm
Beam Angle 38°
Certifications ETL , cETL
Warranty 5-year
