Baffle Trim Slim Square Panel DownlightsBaffle Trim Slim Square Panel Downlights

3"/4"/6"/8" Baffle Trim Slim Square LED Downlights, Ultra Thin Flat Panel Light Fixture with Junction Box, 2700K-6000K Customized Square LED Recessed Panel Lights

Key Features:
Have question? send inquiry to us

Specifications

Model JXL-CF03-T07W-UDD-XX JXL-CF04-T10W-UDD-XX JXL-CF06-T12W-UDD-XX JXL-CF08-T25W-UDD-XX
Style 3" Baffle Slim Square Downlight 4" Baffle Slim Square Downlight 6" Baffle Slim Square Downlight 8" Baffle Slim Square Downlight
Power 7W 10W 12W 25W
Input Voltage 120V AC Dimmable 120V AC Dimmable 120V AC Dimmable 100-277V AC / 0-10V Dimmable
Luminous Flux 500LM 700LM 900LM 2200LM
Dimensions(DxH) 85 x 85 x 11.5mm 120 x 120 x 11.5mm 173 x 173 x 11.5mm 223 x 223 x11.5mm
Cut Out Size 70 x 70mm 110 x 110mm 160 x 160 mm 210mm x 210mm

Products Overview

Baffle Trim Slim Square Panel Downlight
Including 3" 7W / 4" 10W / 6" 12W / 8" 25W dimmable slim square LED downlight, baffle trim light fixture, retrofit installation, 2700K - 6000K customised, junction box included, ETL & energy star listed. No can or housing needed.

Baffle Trim Slim Square Panel Downlight Product Features:

Color Temperature (customized):

Certifications:
