Baffle Style 100-277V Commercial SMD LED Downlights

4"/6"/8" Baffle Style 100-277V Commercial SMD LED Downlights with MC Cable

Key Features:
Have question? send inquiry to us

Specifications

Model JXL-TE04-T12W-UDD-XX JXL-TE06-T20W-UDD-XX JXL-TE08-T25W-UDD-XX
Style 4" Baffle Commercial Downlight 6" Baffle Commercial Downlight 8" Baffle Commercial Downlight
Power 12W 20W 25W
Input Voltage 100-277V AC / 0-10V Dimmable 100-277V AC / 0-10V Dimmable 100-277V AC / 0-10V Dimmable
Luminous Flux 950LM 1800LM 2200LM
Dimensions(DxH) Φ125 X 45mm Φ190 X 55mm Φ227 X 109mm
Cut Out Size Φ102mm Φ165mm Φ195mm

Products Overview

Baffle Style 100-277V Commercial LED Downlight Features:

Color Temperature (customized):

Certifications:
